Blackmagic SDI To HDMI 3G Micro Converter

Blackmagic SDI To HDMI 3G Micro Converter

Blackmagic Micro Converters



The world’s smallest USB powered broadcast converters!



The new Blackmagic Micro Converter 3G models are incredibly tiny broadcast video converters that let you connect between consumer HDMI and professional SDI equipment. The rugged and miniaturised design makes them small enough to be used anywhere! You get professional 3G-SDI connections for working with all SD and HD formats up to 1080p60. Micro Converters use USB for power, so they can be powered directly from televisions or laptop computers. You can even purchase them without power supplies if they are not needed! Only Blackmagic Micro Converters feature custom designed electronics that conform to current global broadcast specifications, and can be updated to new standards in the future.

This model has been specifically designed for professional monitoring. It includes a 17 point 3D LUT for colour calibrating any monitor, projector or television. You can even output the 3D LUT on the SDI loop output! Plus it supports DCI formats and film rates including 1080p24, 1080p47.95 and 1080p48.

  • SDI Video Standards 525i59.94 NTSC, 625i50 PAL

    HD Video Standards 720p50, 720p59.94, 720p60
      1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
      1080PsF25, 1080PsF29.97, 1080PsF30
      1080i50, 1080i59.94, 1080i60
      2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI
      2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI

    SDI Compliance SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M

    SDI Video Rates SDI video connections are switchable between standard definition, 720p 1080i, 1080p and DCI high definition.

    SDI Colour Precision 4:2:2

    SDI Colour Space YUV

    SDI Auto Switching Automatically detects SD, HD and level A or B for 3G‑SDI.

    HDMI Video Standards 525i29.97 NTSC, 625i25 PAL
      720p50, 720p59.94, 720p60
      1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
      1080i50, 1080i59.94, 1080i60

    HDMI Colour Precision 4:2:2. A 17 point LUT can be loaded via the software utility for calibrating or improving monitor color.

    HDMI Colour Space YUV

    Software
    Software Control Mac™ and Windows™ software upgrade via USB.

    Internal Software Upgrade Via USB.

    Operating Systems Mac 10.14 Mojave,
      Mac 10.15 Catalina or later.
      Windows 10.

    Settings Control Via software utility.

    Power Requirements
    Power Consumption 1.6 W

    Operational Voltage Range 4.4V to 5.25V DC

    Environmental Specifications
    Operating temperature 0° to 40° C (32° to 104° F)

    Storage temperature -20° to 60° C (-4° to 140° F)

    Relative Humidity 0% to 90% non-condensing

    Physical Specifications 3.01 x 1.80 x 0.98 inch
